Structural explanation and operation
6. Engine speedometer
Used to indicate the number of revolutions per minute. The red area of the dial indicates that the engine is in a critical speed range, and the engine is prohibited in any case, and the pointer should remain below the critical range. The green area indicates the most cost-effective engine speed range. Driving a vehicle in this green area will save fuel and extend the life of the engine.
7. Current table
The current table is a state of operation of the battery. In normal driving conditions, the current table pointer should be in the range of a small amount of charging (pointer to \"+ \"). If the vehicle is running, the current table pointer is always in the range of discharge (pointer to \"- \"), should be stopped immediately to find out the cause of the failure.
8. Indicate the light board
Steering signal indicator
The lamp is used to indicate the operation of the turret, when the dangerous alarm switch is opened, the left and right steering indicators will flash at the same time. If there is an indicator, the speed is faster than normal speed, indicating that the steering lamp is broken, and the reason should be found in time, replace the steering bulb.
High-light indicator
When the front light of the vehicle uses a remote light. The lamp is light at the same time; the lamp is also bright when the lamp is operated.
Exhaust brake indicator
When the exhaust brake is used, the indicator lights.
Oil pressure alarm light
The key is switched to the \"i \" file position, the lamp is lit. When the engine is started, the lamp is off. If the lamp is lit during the engine operation, it indicates that the oil pressure is abnormal, and it should be dealt with in time.
Note: When the engine has a low pressure, the engine will cause the engine to be burned. When the oil pressure alarm light is on, it is forbidden to continue.
Charging fault alarm light
When the key switch is in the \"i \" position, the lamp lights up. After starting the engine, the light is off. If the charging of the battery is stopped during the driving, the lamp is lit.
Note: When the police report light is on, you should identify the fault in time, otherwise the battery life will be greatly shortened.
Air preheating indicator
Indicates whether the air heater (engine intake preheating device) is passed through a current. When the key switch is on the position of the \"i \" file, the indicator is on, indicating that the air heater begins to warm up. When the indicator flashes, the buzzer can start the engine.
Pneumatic passage light
When the air pressure in the main gas tube is below 3.5 × 100 kPa, the lamp lights up, and the buzzer also alarms. At this time, the air pressure should be asked or eliminating the fault, and then starts.
Note: Insufficient braking air pressure, which is easy to make a traffic accident.
This article is reproduced from: Dongfeng car company - Dongfeng EQ2082E6D off-road vehicle concise instruction manual
